INTEGRATED AMPLIFIER

ADVANCED SEARCH
Rated output power
Rated power consumption
S/N Ratio
MPA-120RS
MPA-120RS
  • Output: RMS 120W;240W
  • 2 Tones(BASS/TREBLE);5 Input volume controls; I MASTER;
  • There are various modules like CD/TURNER/MP3/ECHO/TEL. for option.
  • MP3 player and recording; SD/USB interface
  • MONITOR function; Recording select function;
  • Impedance output is 4; constant voltage output is 25V,70V, 100V; output level display
  • 4 MIC (XLR) inputs; MIC/LINE/PHANTOM exchange SW; I AUX (RCA)INPUT
  • PRE output and AMP input and Line out;
  • 4 ZONE paging with individual volume control and I ALL control of zone paging
Read
MPA-120R ECHO
MPA-120R ECHO
  • Output: RMS 120W;240W
  • 2 Tones(BASS/TREBLE);5 Input volume controls; I MASTER;
  • There are various modules like CD/TURNER/MP3/ECHO/TEL. for option.
  • MP3 player and recording; SD/USB interface
  • MONITOR function; Recording select function;
  • Impedance output is 4; constant voltage output is 25V,70V, 100V; output level display
  • 4 MIC (XLR) inputs; MIC/LINE/PHANTOM exchange SW; I AUX (RCA)INPUT
  • PRE output and AMP input and Line out;
  • 4 ZONE paging with individual volume control and I ALL control of zone paging
Read
TA-512M ECHO
TA-512M ECHO
Read
PAS-150F / PAS-300F / PAS-500F
PAS-150F / PAS-300F / PAS-500F
  • PAS-150F / PAS-300F / PAS-500F: MP3-800 (USB/BT/MF)
  • Switch Mode Power Supply
  • 150W x 1; 300W x 1; 500W x 1 Class-D
  • 4Ω, 70V/100V Outputs
  • 18V DC Phantom Power
  • 4 Line in / MIC Switchable/2 Band EQ/ MIC1 Priority
  • MP3 Player with Bluetooth Receiver
  • TEL Paging / Priority Switch
Read
PAS-150D / PAS-300D / PAS-500D
PAS-150D / PAS-300D / PAS-500D
  • PAS-150D / PAS-300D / PAS-500D:MP3-800(USB/BT/DAB)
  • Switch Mode Power Supply
  • 150W x 1; 300W x 1; 500W x 1 Class-D
  • 4Ω, 70V/100V Outputs
  • 18V DC Phantom Power
  • 4 Line in / MIC Switchable/2 Band EQ/ MIC1 Priority
  • MP3 Player with Bluetooth Receiver
  • TEL Paging / Priority Switch
Read
PAD-60 / PAD-120 / PAD-240
PAD-60 / PAD-120 / PAD-240
  • Signal LED, Clip LED, Power LED
  • 1 AUX (RCA) Input volume adjustments
  • 2 Tone (Bass / Treble) volume adjustments
  • 4 MIC / LINE volume adjustments
  • 1 Master volume adjustments
  • MP3 Player+BT+FM+USB
Read
PAX-60 / PAX-120 / PAX-240
PAX-60 / PAX-120 / PAX-240
  • Output:RMS 60W/120/240W
  • 2 Tones(BASS/TREBLE);5 Input volume controls;1 MASTER;
  • MP3 player with SD/USB interface
  • Impedance output is 4Q;constant voltage output is 70V,100V;output level display;
  • 4MIC(XLR)inputs;MIC / LINE / PHANTOM exchange SW;1 AUX(RCA)INPUT;
  • ECHO Function;
  • High current switching power with class-D amplifier;
  • 1 HU rack 19"size.
Read
