TPS 16P

TSP 10MA/12MA is an active stage monitor speaker, which adopts coaxial PA speaker matching, 2-WAY bass reflex design, black grain paint on the surface, and simple and generous appearance; the module adopts Low 350W/CLSS D+Hi 65W CLSS AB design, and there are two other modes of FOH/Monitor to choose from. TPS 10MA&12MA has the characteristics of high sensitivity, good low-frequency strength, and coordinated mid- and high-frequency sounds. It has a very clean and crisp sound performance and is the preferred professional MONITOR speaker for stage performances.
TPS 16P



  • 2-Way Passive Monitor Speaker
  • RMS Power 70W
  • Input TRS Speaker connector

  • 4xM4 STANDARD
  • Horn Coverage(H*V) 70°H x 70°V XLR

Specification

TPS 16P

2-Way 6.5" Vented PASSIVE Speaker Cabinet

RMS-70Watts Program-140Watts

75Hz-20KHz(-6dB)

110dB Max

2.4KHz@12dB/oct

6.5°(165mm)woofer/1" Voice Coil

1"Neodymium Tweeter

Trapezoidal painted wood cabinet.metal grille

4xM4 Standard(2xVertical and Horizontal side)

12.52"(318mm)x7.87"(200mm)x7.93"(201.5mm)

13.05 lbs/4.2Kg

1.19CFT
