L-Array System <28HA/18SA>

  Active Line Array System
  • L-ARRAY 28HA 8" 2-way Active Speaker System
  • L-ARRAY 18SA 18" Active Line Array Vented Subwoofer
  • L-ARRAY 28HA 800W Continious/1600W Program Power/3200W Peak Power
  • L-ARRAY 18SA 1000W Continous / 2000W Program Power / 4000W Peak Power
L-Array System <28HA/18SA>



L-ARRAY 28HA

  • 8" 2-way Active Speaker System
  • 800W Continious/1600W Program Power/3200W Peak Power
  • 130dB Max
  • Frequency Response:65Hz-20kHz  (-10dB)
  • 2x 8'' Ferrite Woofer , 2'' (50.5mm) Voice Coil
  • 2x 1'' Neodymium Compression Driver, 1.35''  (34mm)Voice Coil
  • Dispersion(-6dB):110° Horizontal, 15° Vertical
  • Attachment Points: Vertical Splay Adjustable in 1.0° Increments from 0°-12°

  • Connections: Input: 1 x Combo-XLR&1/4”Balanced/Unbalanced Line Input
    Output: 1 XLR Thru Balanced line

  • Network I/O: Input: 1 x etherCON(RJ45) Input
     Output: 1 x etherCON(RJ45) Outpua



    L-ARRAY 18SA

  • 18" Active Line Array Vented Subwoofer
  • 1000W Continous / 2000W Program Power / 4000W Peak Power
  • 135dB Max
  • Frequency Response:35Hz–150Hz(-10dB)
  • 18''Ferrite Woofer, 4"(100mm)Voice Coil with Long Excursion
  • 4 MIC / PHANTOM/LINE switch

  • Connections: Input: 1 x Combo-XLR&1/4”Balanced/Unbalanced Line Input
    Output: 1 XLR Thru Balanced line

  • Network I/O: Input: 1 x etherCON(RJ45) Input
    Output: 1 x etherCON(RJ45) Output

Specification

System Type
8"2-way Active Line Array Loudspeaker System
Output Power
800W Continious/1600W Program Power/3200W Peak Power Class D@8 Ohms
Maximum SPL @1m
130dB Max. (calauated)
Frequency Response
65Hz-20kHz(-10dB)
Transducer Low
2×8"Ferrite Woofer,2"(50.5mm)Voice Coil
Transducer High
2x1"Neodymium Compression Driver,1.35"(34mm)Voice Coil
Crossover Frequency
1.8kHz
Dispersion(-6dB)
110°Horizontal,15°Vertical
Attachment Points
Adjustable Rigging System,Vertical Splay Adjustable in 1.0°Increments from 0°-12°
Connections
Input:1x Combo-XLR&1/4"Balanced/Unbalanced Line Input Output:1 XLR Thru Balanced line
Network I/O
Input:1x etherCON(RJ45)Input; Output:1x etherCON(RJ45)Output.
DSP Processor
Venue Settings(Adjustable via Optional Software) 32bit,24bit/48kHz Audio Conversion AD/DA,Digital Volume Control
External Controls
9 Presets EQ/1 Service Use Power ON with Green LED,Clip/SIG/PROT with LED
Electronic Protections
Over heat Protection/Short Circuit Protection/Digital Compressor
Enclosure Construction
Polypropylene enclouse,Steel Grille with foam,Two Handles on Each Side.
Fittings information
4Flying Points
Mounting
4-Point Suspension,Three Configuration Styles(Small,Stack and Array)
Dimensions(HxWxD)
(H)292mm*(W)594mm*(D)420mm
Net Weight
Approach 21.5kg

System Type
18"Active Line Array Vented Subwoofer
Power Rating
1000W Continious/2000W Program Power/4000W Peak Power Class D@8Ohms
Transducer Low
18"Ferrite Woofer,4"(100mm)Voice Coil with Long Excursion
Frequency Response
35Hz-150Hz(-10dB)
Maximum SPL @1m
135dB(calauated)
Connections
Input:1×Combo-XLR&1/4"Balanced /Unbalanced Line Input Output:1 XLR Thru Balanced line
Network I/O
Input:1x etherCON(RJ45)Input; Output:1x etherCON(RJ45)Output.
DSP Processor
Venue Settings(Adjustable via Optional Software) 32bit,24bit/48kHz Audio Conversion AD/DA,Digital Volume Control
External Controls
9 Presets EQ/1 Service Use Power ON with Green LED,Clip/SIG/PROT with LED
Electronic Protections
Over heat Protection/Short Circuit Protection/Digital Compressor
Enclosure Construction
Plywood Cabinet,Resistant Black Paint,Metal Grille with Foam,Rubber Feet, Four Handles on Each Side.
Fittings information
4Flying Points
Mounting
One Metal Standard Pole-Mount
Dimensions(WxHxD)
(H)692mm*(W)594mm*(D)766mm
Net Weight
Approach 68.8Kg
