TC-1240 / TC-1440 / TC-1640

  • Round type horn speaker
  • Horn speakers of aluminum material
  • High effect and 8 Ω impedance
TC-1240 / TC-1440 / TC-1640

This series is a waterproof series of aluminum speaker (main body), with ferrite magnet as the external magnetic speaker head design, containing an 8 Ω, 40 W speaker head unit, integrated with the aluminum speaker, with high sensitivity, long sound diffusion distance, high efficiency, and clear sound range performance;
Widely used in public places such as hotels, restaurants, airports, office buildings, churches, ships, etc., PA speaker products can be used as part of the voice alarm system to provide alarms to people in or near the building where a fire emergency occurs, and enable these people to take pre-determined measures in the evacuation plan.



規格

Rated lnput Power
40 W
Preset lmpedance
8 Ω
頻率響應
250 ~ 6 kHz
Sound Pressure level
106 dB (1 W/M)
Dimensions (H * L)
Aluminum
Φ316 mm * 283 mm

Rated lnput Power
40 W
Preset lmpedance
8 Ω
頻率響應
250 ~ 5.5 kHz
Sound Pressure level
109 dB (1 W/M)
Dimensions (H * L)
Aluminum
Φ368 mm * 317 mm

Rated lnput Power
40 W
Preset lmpedance
8 Ω
頻率響應
250 ~ 5 kHz
Sound Pressure level
112 dB (1 W/M)
Dimensions (H * L)
Aluminum
Φ398 mm * 360 mm
