SC-10AH / SC-15AH / SC-30AH

  • This series of speakers uses aluminum body (speaker tube)
  • Outdoor fully waterproof IP66 series products,
  • Contains an intermediate transformer to match the impedance for 100 V, 25 V, 70 V high voltage input, can be configured with PA amplifier for use,
  • Ferrite magnet for external magnetic speaker head design, with high efficiency and wide sound range performance.
SC-10AH / SC-15AH / SC-30AH

This series of speakers are fully waterproof products made of aluminum and plastic speaker tubes (body). The ferrite magnet external magnetic speaker head is designed and used with high efficiency and wide sound range. It has passed the waterproof IP66 level certification and is widely used in public places such as hotels, restaurants, airports, office buildings, churches, and ships. For this reason, PA speaker products can be used as part of the voice alarm system to provide alarms to people in or near buildings where fire emergencies occur, and enable these people to take predetermined measures to evacuate the plan.
SC series are plastic speakers, with the same appearance design, and the speakers are square.



規格

Rated lnput Power
10 W(100 V定壓線路)
lnput lmpedance
1 kΩ/2 kΩ/3.3 kΩ/10 kΩ
Preset lmpedance
1 kΩ
頻率響應
315 ~ 12.500 Hz
Sound Pressure level
105 dB/W/m
Dimensions (H * L)
ABS resin
(176 mm * 125.5 mm) * 179.5 mm

Rated lnput Power
15 W(100 V定壓線路)
lnput lmpedance
670 Ω/1 kΩ/2 kΩ/3.3 kΩ/10 kΩ
Preset lmpedance
670 Ω
頻率響應
280 ~ 12.500 Hz
Sound Pressure level
108 dB/W/m
Dimensions (H * L)
ABS resin
(222 mm * 161.5 mm) * 227.5 mm

Rated lnput Power
30 W(100 V定壓線路)
lnput lmpedance
330 Ω/670 Ω/1 kΩ/2 kΩ/3.3 kΩ/10 kΩ
Preset lmpedance
330 Ω
頻率響應
250 ~ 16.000 Hz
Sound Pressure level
109 dB/W/m
Dimensions (H * L)
ABS resin
(287 mm * 208 mm) * 257.5 mm
